Microservice Grid and Micro Frontends

adam_naming_the_animals-_etching-_wellcome_v0034186
Adam naming the animals, Wellcome Library, London. Source: Wikimedia Commons.

This post is not here to bring you anything new as it is for me to run a victory lap. If there is anything I blogged about with any consistency, it was about microservices. There are many articles in this blog addressing various problems you may face when attempting a microservice system of a non-trivial scale. One area I was particularly keen on was decomposition of the front end in a way similar to what we did in the back.

You would think that it goes without saying, but a lot of microservice noise was focused on the backend. I understand that: breaking the big server into a number of smaller ones behind a routing proxy is easier to understand. REST API is REST API is REST API. A number of endpoints per microservice neatly collate into a complete system with use of session-less API services.

But what’s good for the goose ought to be good for the gender. Slapping a massive, unruly front end server in front of a nice microservice API system does not help us much, other than to highlight the irony of the half-hearted approach. That’s why I focused a lot of this blog on composing the UI microservices as well. From your favorite article on microservice authentication, to UI composition, to isomorphic microservices using Node.js and React.

Far from being armchair generals, we put our money where our mouth is, applying these ideas in production, learning more in each successive generation. The last name for this approach I used was microservice grid:

microservice-gridThe picture above represents the essence of our current approach. It is uniform in that horizontally it represents tiers (front end, back end, optional hosted legacy apps in containers). Three buses provide glue – UI domain for bringing all paths under the same URL, API domain for collating all API endpoints, and an event bus to glue the microservices using a message broker of some kind.

Vertically, each column of the grid represents a feature. What I like about this approach is that unlike with big monolith apps, adding features does not make everything bigger and slower. Adding a new feature vertical does not affect the performance of the existing verticals.

So that’s what you call it

One of my favorite hobbies now is going to Technology Radar published by ThoughtWorks and looking for how they are naming a technique we are already using in production. For example, the pattern of providing a single API gateway for your client side code is now called Back End for Front end. But what gave me no end of pleassure was that now the whole approach of this blog that I spent so much time writing about has an official name: micro frontends.

We’ve seen significant benefit from introducing microservice architectures, which have allowed teams to scale delivery of independently deployed and maintained services. However, teams have often struggled to avoid the creation of front-end monoliths—large and sprawling browser applications that are as difficult to maintain and evolve as the monolithic server-side applications we’ve abandoned. We’re seeing an approach emerge that our teams call micro frontends. In this approach, a web application is broken up by its pages and features, with each feature being owned end-to-end by a single team. Multiple techniques exist to bring the application features—some old and some new—together as a cohesive user experience, but the goal remains to allow each feature to be developed, tested and deployed independently from others. The BFF – backend for frontends approach works well here, with each team developing a BFF to support its set of application features.

Technology Radar, Nov 2016, ThoughtWorks

Like with Adam in the engraving above, things exist before they are named, but Nomen est Omen – naming our approach in a way that offers a nice symmetry with micro services gives it a renewed meaning and is a success in my book.

Therefore, go forth and build your microservice grids, your micro frontends, your Backends for Frontends, you princes of Maine, you kings of New England.

© Dejan Glozic, 2017

The Web of Hooks

hooks

It’s a new year, which means it is time to update the copyright at the bottom. I have been busy lately and I didn’t want to write fluffy blogs just to fill the space. But this time I actually have real content, so here it goes.

If you followed my blog in the past, you know I was very bullish on message brokers in the context of microservice architecture. I claimed that REST APIs alone are not sufficient to sustain a successful microservice system. Event collaboration pattern is necessary to ensure a scalable and robust system where microservices that own resource lifecycle don’t need to be burdened with executing all the code driven by that lifecycle. You can read more about it in my article about REST/MQ mirroring.

Not so fast

There is a fly in this particular ointment, however. While HTTP REST is well understood, messaging protocols are numerous. You may know from my writing that I liked MQTT for a while due to its simplicity and wide support. However, MQTT is actually not a great protocol for gluing your microservice system. It is designed to be lightweight and run on the smallest of IoT devices, and lacks some critical features such as anycast support and manual acknowledgement of messages.

Another popular protocol (AMQP) suffered a schism of sorts. The version supported in a popular RabbitMQ broker (0.91) is a very different protocol from an actual open standard AMQP 1.0 that is not as widely supported. This is a pity because I really like AMQP 1.0. It is like MQTT but with anycast and manual acknowledgment – perfect as a microservice system glue, yet still very simple to work from within clients.

And of course, there is Apache Kafka, a very powerful but odd choice given its origins in high-throughput distributed log aggregation. Kafka is unapologetically Java-centric, has a proprietary protocol and bolt-on REST APIs to connect client languages are still fairly low level. For example, where AMQP 1.0 guarantees quality of service and requires implementations to provide a buffer of messages that are re-delivered to a client that crashed, Kafka simply allows you to maintain a pointer in the queue but it is your job to work up the queue and catch up after restarting. You pay for performance by working at a level fairly low for general purpose application messaging.

Authentication pains

Choosing the messaging solution and protocol is only one part of the problem. If you want your system to be extensible and allow third-party integrations, you need to make it fairly easy for new clients to connect. On the other hand, you need to secure the clients because you don’t want a rogue app to eavesdrop on the events in the system without authorization (otherwise you have this egg on the bot face). Maintaining a large list of clients connected to the same topics can also be an scalability issue for some brokers.

For all these reasons, it has been widely acknowledged that message brokers are not a good match for external integrations. A cursory scan of popular cloud applications with large ecosystems all point at a more client-friendly alternative – WebHooks.

WebHooks to the rescue

You would think that if something is so popular and has a catchy name, there is an actual well written protocol for it. Wrong! WebHooks is the least common denominator you could imagine. In a nutshell, this is all there is:

  • You publish a list of valid events for which you will notify clients
  • You provide an API (and/or UI) for clients to register URLs for one or more of those events
  • When an event happens, you execute HTTP POST on the URLs registered for that event type.

That’s all. Granted, message brokers have topics you can publish and subscribe, and the actual messages they pass around are free-form, so this is not very different. But absent from WebHooks are things such as anycast, Quality of Service, manual acknowledgement etc.

I don’t intend to go into the details of what various implementations of WebHooks in apps such as GitHub, Slack etc. provide because thankfully Giuliano Iacobelli already wrote such an article. My interest here is to apply this knowledge to a microservice system we are building and try to anticipate pros and cons of going with WebHooks.

What it would take

First thing that comes to mind is that in order to support WebHooks, we would need to write a new WebHook service. Its role would be to accept registrations, and store URL and event type mappings for subsequent invocation. Right there, my first thought is about the difference between external and internal clients. External clients would most likely use the UI to register a URL of their integration. This is how you register your script in GitHub so that it runs on every commit, for example.

However, with internal clients we would have a funny problem: every time I restart a microservice instance, I would need to register somewhere in startup. That would make a POST endpoint a nonstarter, because I don’t want to keep creating new registrations. Instead, a PUT with a client ID would work better, where an existing registration for the same ID would just be updated if already there.

Other than that, the service would offer a POST for a new message into the provided event type that would be delivered to all registered URLs for that type. Obviously it would need to guard against 404s, 502s and URLs that take too long to return response, giving up on them after a set timeout.

The best of both worlds

The set timeout brings back the topic of the quality of service, implying that WebHooks are great for external integration but not that great for reliable glue of a microservice system. Why don’t we marry the two then? We could continue to use message broker for reliable delivery of internal messages, and hook it up to a WebHook service that would notify external integrations without the need to support our particular protocol, or get too much access into the sensitive innards. Hooking up a WebHook service to a message broker would have the added benefit of buffering the service itself so that it can be restarted and updated without interruption and missed events.

webhooks

In the diagram above, our microservice system has the normal architecture with a common routing proxy providing a single domain entry into the microservices. The microservices use normal message broker clients to publish to topics. A subset of these topics deemed suitable for external integrations is also listened to by the WebHook service, and for each of those messages it reaches into the stored list of registrations and calls HTTP POST on the registered URLs. If the WebHook service crashes, a reputable message broker will maintain a buffer of messages to re-deliver them upon restart. For performance reasons, WebHook service can choose to keep a subset of registrations in the in-memory cache depending on how frequently they are used.

Discussion

Obviously registering a URL with an HTTP PUT is much easier to implement, and providing a single POST endpoint to handle the event lowers the barrier of entry for external integrations. In fact, hooking up code to react to a single POST could very well be done using serverless architecture.

Are we losing something in the process? Inserting another service into the flow will add a bit of a delay but external notifications are normally for events that are not happening many times a second, so the tiny delay is more than acceptable tradeoff. In addition, if the client providing WebHook URL is itself load-balanced, this delivery will be hardcoded to anycast (the event notification will only hit one of the instances in the cluster).

Finally, this creates two classes of clients – ‘inner circle’ and external, segregated clients. Inner circle is hooked up directly to the message broker, while the external clients go through the service. In addition to this being an acceptable price to pay for easier integration, it is useful to be able to only expose a subset of events externally – some highly sensitive internal events may only be available to ‘trusted’ clients subscribing to message broker topics and having internal credentials.

Since the WebHook service will normally not keep retrying to deliver an event to an unresponsive URL, it is possible to miss an event. If this is a problem, external system would need to fashion a ‘belt and suspenders’ fortification, where event driven approach is augmented with a periodic REST API call to ‘compare notes’ and ensure the baseline it is working against is up to date.
